Feature：
10W High Power
DMR Digital machine
Digital+Simulate
800 Used contacts
Voice encryption/Emergency alarm
FM Radio
32 scan lists and 16 regions
TDMA dual slot direct dual capacity
Digital recording(10H)
GPS/APRS(optional)
Large capacity recording(optional)

CMIIT ID：
2022FP13417

GENERAL：
Frequency：VHF:136-174MHz UHF：400-470MHz
Channel capacity：1024個(gè)
Channel space：25KHz/12.5KHz
Battery capacity capacity：DC7.4V±20% 4800mAh
Frequency stability：±0.5ppm
Work temperature：-30℃～+60℃
Storage temperture：-40℃～+85℃
Size：139mm*58mm*35mm
Weight：300g
Antenna impedance：50Ω

TRANSMITTER：
Power：10W
FM Modulation：11KΦ[email protected]；16KΦF3E@25kHz
4FSK Digital modulation method：7K6ΦFXD@Data；7K6ΦFXW@Data and Voice
Digital Vocoder Type：AMBE++
Digital protocol：ETSI-TS102,361-1,-2,-3
Conduction/Radiation stray：-36dBm＜1GHz；-30dBm＞1GHz
Communication sound and noise：≥[email protected]；≥-45dB@25kHz
Spurious radiation：-36dBm＜1GHz；-30dBm＞1GHz
Simulate adjacent channel power ：≥[email protected]；≥70dB@25kHz
4FSK Modulation accuracy：≤5%
Modulation frequency offset limitation：≤±[email protected]
Radio distortion：≤5%
Radio response：300-3KHz，+1/-3dB

RECEIVER：
Simulate sensitivity：≤-121dBm@12dB SINAD
Digital sensitivity：≤-119dBm@5% BER
Intermodulation：[email protected]/25kHz
Channel selectivity：≥[email protected]；≤70dB@26kHz
Common channel suppression：0～[email protected]/25kHz
Rated radio power：＞1W
Rated radio distortion：≤5%
Communication sound and noise：≥[email protected]；≥-45dB@25kHz
Conduct stray radiation：＜-57dBm
